BOXER 24 (24-MIX & 240) is a two-diaphragm pump, built to obtain high quality finishing! It's very easy and handy. The two-diaphragm system allows to feed the spray gun without pulsation and keeps a constant atomisation.

Construction specifications:
BOXER 24 MIX is a pneumatic double diaphragm pump built-up to feed all types of air guns: volumetric, automatic, HLVP, etc..
On request, BOXER 24 MIX, can be supplied with hopper for a direct suction which assures a constant feed of the product to the gun. No lubrication and maintenance needed.

Performances:
  • Light and handy
  • No maintenance
  • Very low air consumption
  • No lubrication
  • Recommended gun: TAIVER T88
  • Pneumatic mixer on request
  • Parts in contact with product anti-acid and fireproofing treated

 #013900






  Destination's field   Applications   Suggested guns
  Wood industry
  Mechanical industry
  Carpentry
  Third party painting
  Paint
  Thixotropic products
  Latex
  Water based products
  not abrasive paints
  T88

  T 2004 HVLP

  Motor Type: Pneumatic
  Max. Pressure: 8 Bar
  Ratio: 1:1
  Weight: 13 Kg
  Max. Delivery:  24 lt/min



BOXER 24 explosion drawing.pdf
